When it comes to manufacturing splines, accuracy isn’t just important—it’s essential. Splines are the unsung heroes of mechanical assemblies. They transfer torque, align parts, and hold components in place without fail. Broaching for splines is a key process that ensures their performance depends entirely on how precisely they’re made.
Enter broaching.
Broaching for splines is one of the most reliable and efficient methods available when you need consistent, high-precision cuts, especially at scale. It’s a process that’s been around for a long time, but it’s still a go-to solution for a reason. When executed properly, broaching delivers clean, repeatable results that meet tight tolerances without dragging out production timelines.
So let’s look at how broaching works, why it’s ideal for spline cutting, and when it’s the right call for your project.
What Is Broaching, Anyway?
If you’re not familiar with the term, broaching is a machining process that removes material using a tool called a broach. A broach looks a bit like a saw blade or file—except it has a series of teeth that increase in size from front to back. Each tooth takes a little more material than the one before it, which allows the tool to create a finished shape in a single pass.
That’s what makes broaching so efficient. Instead of making multiple cuts or passes like in milling or turning, you get the entire profile done at once. It’s fast, repeatable, and perfect for internal forms like keyways, slots, or, you guessed it, splines.
Why Broaching Works So Well for Splines
Broaching for splines has a few distinct advantages over other spline cutting methods. First and foremost, it’s about consistency. If you need to cut dozens, hundreds, or even thousands of identical splines, broaching can deliver with incredible repeatability.
Because the broach tool is custom-designed to match the desired spline profile, it guarantees uniformity from part to part. That level of control is hard to beat, especially when tight tolerances and perfect alignment are non-negotiable.
Plus, broaching doesn’t require complex part fixturing or time-consuming setups. Once the tool is in place and aligned, you’re good to go. That means less downtime and more productivity, especially valuable when you’re scaling up production.
Spline Cutting Methods: How Does Broaching Compare?
There’s more than one way to cut a spline, and each method comes with its pros and cons. So how does broaching stack up?
Let’s take a quick look at some common spline cutting methods:
Milling
Milling is versatile and can be used for both internal and external splines. However, it often requires multiple passes, careful alignment, and slower speeds—especially for internal splines. That makes it better suited for prototyping or low-volume runs.
Shaping
Shaping involves a reciprocating cutting tool that slowly carves out the spline profile. It can produce accurate results, but it’s slower than broaching and generally not ideal for high-volume applications.
Hobbing
Hobbing is a great option for external splines and gears. It’s fast and efficient, but doesn’t work well for internal splines, which is where broaching has the upper hand.
Wire EDM
Electrical discharge machining (EDM) is used when extreme precision is needed, or when the material is too hard for traditional machining. It’s accurate, but also slow and expensive. Not ideal for large production runs.
Broaching
Broaching strikes a sweet spot. It offers tight tolerances, quick cycle times, and incredible repeatability for internal splines. For large batches of parts that need to be just right, broaching is often the most efficient path.
The Process of Broaching a Spline
Let’s walk through what broaching for splines looks like in the shop.
Step 1: Preparing the Part
Before broaching can happen, the workpiece usually needs a pre-machined pilot hole or bore. This gives the broach a starting point and helps guide it into position.
Step 2: Choosing the Broach
Broaches are custom-made to match the exact geometry of the spline. That includes the number of teeth, tooth profile, pressure angle, and internal dimensions. The design ensures that each tooth on the broach removes just the right amount of material in a smooth, progressive cut.
Step 3: Performing the Cut
The broach is pushed or pulled through the pre-machined hole using a broaching machine. Depending on the material and size, the machine might be hydraulic or mechanical. As the broach moves through the part, each tooth removes more material, forming the spline profile as it goes.
Step 4: Finishing and Inspection
Once the broach has passed through, the part is usually deburred and cleaned. It may also go through a round of inspection using gauges or coordinate measuring machines (CMM) to ensure it meets the specifications.
It’s straightforward, repeatable, and, when done right, yields exceptional results.
Materials and Limitations
Broaching works best with materials that are firm but not overly hard. Most steel alloys, aluminum, brass, and bronze can be broached effectively. However, materials that are too hard or abrasive (like hardened tool steels or certain composites) can wear down the broach too quickly.
That’s not to say you can’t broach hard materials. It just takes a different approach, maybe a more robust machine, a coated broach, or even a shift to another spline cutting method like wire EDM.
Another thing to keep in mind: broaches are custom tools. That means there’s an up-front investment for design and manufacturing. It’s why broaching shines in medium to high production volumes. If you only need five parts, broaching might not be cost-effective. But if you need five thousand? It’s a great choice.
What Makes Broaching So Precise?
In the world of precision machining, broaching has earned its reputation. It might seem simple, but behind the scenes, it’s a highly engineered process. The tool geometry is carefully calculated. The feed rates, machine pressure, and cutting speed are all tuned to deliver consistent results.
Because the broach makes the full cut in one pass, there’s less risk of variation due to tool wear or human error. And with fewer tool changes and simpler setups, the process minimizes chances for things to go wrong.
When you need splines to perform under load, align perfectly, or interface with mating components without fail, broaching provides the confidence you’re looking for.
Scaling Production Without Sacrificing Quality
One of the best things about broaching for splines is how well it scales. Once your process is dialed in, you can run part after part with almost no variation. That’s exactly what industries like automotive, aerospace, and heavy machinery need—reliable components that meet spec every single time.
At C. Thorrez Industries, Inc., we’ve built our reputation on delivering that kind of consistency. We don’t just cut splines, we engineer solutions that fit your project, your production volume, and your budget.
And because we handle a wide range of precision machining services in-house, we can manage your entire process from raw material to final inspection. That keeps your timelines on track and ensures every part meets our strict quality standards.
A Partner You Can Count On
Choosing the right spline cutting method isn’t just a technical decision—it’s a business one. You need a partner who understands the big picture. Someone who can help you weigh the trade-offs between cost, volume, precision, and lead time.
That’s where we come in.
At C. Thorrez Industries Inc., we bring decades of experience to the table. We’ve helped companies across industries streamline production, improve part performance, and save money by choosing the right processes for their specific needs.
If broaching for splines is the right fit, we’ll tell you. If another method makes more sense for your goals, we’ll walk you through that too. It’s not about selling you a service. It’s about making your project successful from start to finish.
